Foundation Mounting Bracket
Seamlessly Secure Power Pedestals to a Variety of Side Surfaces
Already have a Part Number?
Enter part number to get started
Downloads
The Pedoc Foundation Mounting Bracket allows power access where a stable ground surface isn’t available. This side-mount design provides secure placement on walls, docks, pavers, railroad ties, cement forms, and other challenging surfaces—enhancing adaptability, enabling clean conduit routing, and expanding power access to locations traditional mounting can’t reach.
- Expand Flexibility: Pedestals securely mount to side surfaces like walls, docks, pavers, railroad ties, or cement forms using the foundation mounting bracket
- Save Time: Quick and easy installation with minimal disruption to the surrounding landscape
- Simplify Maintenance: Durable, welded construction that minimizes costly repairs over time
- Optimize Functionality: Open bottom accommodates variety of conduit raceway sizes
Choose Your Configuration
3D Viewer (Select a pedestal configuration)
Downloads
Specifications
Compatibility
| Compatible Models: | Pedoc integral base and internal mounting pedestals |
| Surface Compatibility: | Walls, docks, pavers, railroad ties, cement forms, and other hardscape substrates |
Electrical
| Conduit Capacity (PED0504): | Up to (2) 2″ conduit raceways |
| Conduit Capacity (PED0520): | Up to (2) 1-1/2″ conduit raceways |
| Conduit Capacity (PED0530): | Up to (2) 1″ conduit raceways |
| Routing Method: | Open-bottom design allows direct conduit entry into pedestal |
Material and Design
| Material: | .160″ 5052-H32 welded aluminum |
| Mounting Plate Holes: | (4) × ½″ diameter holes for pedestal fastening |
| Included Hardware: | (4) 5/16″-18 × 1″ SS button-head screws; (8) SS washers; (4) 5/16″-18 SS hex nuts |
| Finish Options: | Bronze, Black, or custom RAL color (customer-supplied paint chip required) |
Additional
| Country of Origin | Made in USA – Manufactured and assembled in Mt. Prospect, IL |
| Customization: | Custom colors (customer-supplied paint chip required) and additional device openings available |
| Compatible Pedestal Part Number | Catalog Number | Description | Finish | Product Page | UPC | Drawing |
|---|---|---|---|---|---|---|
| Beginning with 5P (5×5 with Integral Base), Black | PED0504-B | FOUNDATION MOUNTING BRACKET – 5P, Black | Black | View | 00810147448883 | Drawing |
| Beginning with 5P (5×5 with Integral Base), Bronze | PED0504-BRZ | FOUNDATION MOUNTING BRACKET – 5P, Bronze | Bronze | View | 00810147448890 | Drawing |
| Beginning with 1P & 2P, Black | PED0520-B | FOUNDATION MOUNTING BRACKET - 1P and 2P, Black | Black | View | 00810147448906 | Drawing |
| Beginning with 1P & 2P, Bronze | PED0520-BRZ | FOUNDATION MOUNTING BRACKET – 1P and 2P, Bronze | Bronze | View | 00810147448913 | Drawing |
| Beginning with 4FMIM (4x4 Flush Mount), Black | PED0530-B | FOUNDATION MOUNTING BRACKET – 4x4, Black | Black | View | 00810147448920 | Drawing |
| Beginning with 4FMIM (4x4 Flush Mount), Bronze | PED0530-BRZ | FOUNDATION MOUNTING BRACKET – 4x4, Bronze | Bronze | View | 00810147448937 | Drawing |
Outdoor-Rated Powder Coat Finishes (Standard & Custom Options)
These heavy-duty finishes are UV- and corrosion-resistant for year-round outdoor use. Colors shown are representative only. Request a sample chip at info@pedocpower.com.
Custom colors available upon request – customer-supplied paint chip required.
Black (B)
Bronze (BRZ)
